• Model NO.：ZQ-BM3-03A
• Condition：New
• General Use：Hospital Furniture Hospital Bed
• Height：510-800mm
• PP Guadrails：Foldable up and Down Easily
• Headboard：PP
• Optional Configuration：Mattress,Over Bed Table,Oddment Shelf
• Bed Plate：4 Plate Board
• Castor：150mm
• Transport Package：Carton with Pallet
• Specification：2200*1070mm
• Origin：China

Basic Info.

Model NO. ZQ-BM3-03A Condition New General Use Hospital Furniture Hospital Bed Height 510-800mm PP Guadrails Foldable up and Down Easily Headboard PP Optional Configuration Mattress,Over Bed Table,Oddment Shelf Bed Plate 4 Plate Board Castor 150mm Transport Package Carton with Pallet Specification 2200*1070mm Origin China

Product Description

1. Bedboard: galvanized cold-rolled steel one-time impact briquet, the surface is smooth without welding marks. Load capacity is 250 KG.
2. Central locking features: controlled by the brake pedal, four casters brake when the control pedal is pressed, and four casters unlocked when lifting the pedal.
3. Bed frame: galvanized cold-rolled steel pipe by robot 360° completely smooth welding.
4. All parts are anti-corrosive and resistant to hospital-grade disinfectant products.
5. ABS virgin material (not recycled), environment friendly, and healthy for patients care.
6.Aluminum alloy guardrail, foldable, convenient for patients to get in and out of bed
7.ABS bed head, hanging installation, easy disassembly
8. Optional parts: mattress, retractable table, over-bed table, bedside cabinet.
9. Mattress material: non-toxic and non-carcinogenic materials, antibacterial, nonallergic, water-resistant, resistant to hospital-grade disinfectant products.


Parameter
Product Name	3 function manual bed
Back-rest	0-75°±10°
Leg-rest	0-35°±10°
Height Adjustment	480-720mm
External size (LxWxH)	2100*970*480mm
Bedboard size	1925 * 900mm
Mattress size	1900x900*80 mm
Drainage hook	2 pcs
IV pole	1 set
