• Model NO.：ZQ-BM3-04P
• Condition：New
• General Use：Hospital Furniture Hospital Bed
• Height：420-660mm
• Guadrails：Foldable up and Down Easily
• Headboard：PP
• Optional Configuration：Mattress,Over Bed Table,Oddment Shelf
• Bed Plate：4 Plate Board
• Castor：150mm
• Transport Package：Carton with Pallet
• Specification：2200*1070mm
• Origin：China

Basic Info.

Model NO. ZQ-BM3-04P Condition New General Use Hospital Furniture Hospital Bed Height 420-660mm Guadrails Foldable up and Down Easily Headboard PP Optional Configuration Mattress,Over Bed Table,Oddment Shelf Bed Plate 4 Plate Board Castor 150mm Transport Package Carton with Pallet Specification 2200*1070mm Origin China

Product Description

Main Features:

1. Epoxy coated bed frame, welded by square steel tube, very firm.
2. The bed-board adopts cold-roll steel sheets, which are integrated punch-formed at one time, with air holes, nice, solid and reliable.
3. The bed head/footboard is assembled by ABS engineering plastic,detachable, arc, smooth, with acrylic info card frame on foot end.
4. Equipped with a pair of big ABS guard rails, collapsible, easy to operate.
5. Three function: (operated by cranks)
(1) back rest:0º-70º±2º (2) knee rest:0º-40º±2º (3) down-up: 460/680mm
6. Three ABS hidden cranks, space-saving, easy to operate.
7. Four Dia. 125mm double-side castors, each with individual brake.
8. Anti-bumper in four corners, with I.V. rod locations.
9. Optional Accessories: I.V. rod, mattress, food tray, overbed table,bedside cabinet and bedside table.



Dimension	2150mm(L)×940mm(W)×460mm/680mm(H)
Finishing	Epoxy powder coating
Bed Frame	Cold rolling steel square tube
Bed-Board	4-part steel plate
Head & Foot Board	ABS engineering plastic detachable
Side Rail	2 ABS big guard rails
Bed Wheel	4 two-sided castor 5″ with individual brake
Back Raise	0º-70º±2º, adjust by crank
Knee Raise	0º-40º±2º, adjust by crank
Height Raise	460mm-680mm, adjust by crank
(Reverse) Trendelenburg	NO
Crank	3 ABS hidden crank
Optional	Infusion stand, mattress, bedside cabinet, food tray, overbed table
