• Model NO.：FY012
• Input Voltage：24V
• Stroke：50~1000mm Optional
• Protection Class：IP54
• Mini Install Dimension：S+175mm
• Limit Switches：Inner
• Warranty：2 Years
• Type of Duty：S2-10min
• Usage：Furniture Equipment,Sofa
• Transport Package：in Standrd Box or as Required
• Specification：4000N
• Trademark：JDR
• Origin：Jiangsu, China (Mainland)
• HS Code：940190900
• Production Capacity：1, 4000PCS,Month

Basic Info.

Model NO. FY012 Input Voltage 24V Stroke 50~1000mm Optional Protection Class IP54 Mini Install Dimension S+175mm Limit Switches Inner Warranty 2 Years Type of Duty S2-10min Usage Furniture Equipment,Sofa Transport Package in Standrd Box or as Required Specification 4000N Trademark JDR Origin Jiangsu, China (Mainland) HS Code 940190900 Production Capacity 1, 4000PCS/Month

Product Description

Input Voltage: 24 v DC

Load Capacity: 6000N

Max Speed: 4MM/S(4000N), 9mm/s(2000N)

Stroke: 0~1000mm(option)

Type of duty: S2-10min

Limit switches: Inner

Operation Temperature: -26--65 centigrade

Protection Class: IP54

Certification: CE/EMC+LVD, RoHS

Type: Furniture part

Material: Metal and plastic

Use: Traction bed

Place of origin: Jiangsu, China(mainland)

Function: Driving

Shape: Linear

Power: DC

More inforamtion

1) 24VDC permanent magnet motor

2) Thrust up to 6000N in push, and up to 4000 N in pull

3) Elegant and compact design with small instanllation dimensions

4) Built-in limit switches ( not adjustable after leaving factory )

5) Aluminium or zinc outer tube / inner tube

6) Electric chromate steel piston rod eye with slot

7) High-strength plastic housing protects motor and gears

8) Standard protection class: IP 54

9) Scratch and wear-resistant power painting

10) Noise level < 50 dB

11) Warranty: Two years

12) Duty cycle: 10%, or 2 munutes continous working followed by 18 minutes not in use
