Hospital Medical Electric Motor Multifunction Surgical Table (ECOH005)
Shanghai MedEco Industry Co., Ltd.- Material：Stainless Steel
- Type：Operating Table
- Folded：Folded
- Using Ambient：Hospital
- Numbers of Function：Three-function
- Certification：CE, ISO13485
Base Info
- Model NO.：ECOH005
- Condition：New
- Table Height：600mm~950mm
- Length and Width：2100mmx500mm
- Reversed Trendelenburg/Trendelenburg：20o
- Lateral Tilt (Left/Right)：15o
- Head Rest(up/Down)：45o,90o
- Back Rest (up/Down)：75o,30o
- Footboard(up/Down&Horizontal Position)：90o,90o
- Longitudinal Sliding：350mm
- Transport Package：Standard Export Packing Box
- Specification：CE
- Trademark：MEDECO
- Origin：China
- Production Capacity：5000PCS,Year
Description
Range of movements:
Reversed Trendelenburg........…≥20° Trendelenburg...........................≥15°
Lateral Til....................................≥15° Backward and Forward Movements.........≥350mm
Adjustment of sections:
Leg section opened................ ....≥90° Back rise(When optional)..........≥80mm
Lifting speed...............................4~16mm/s Safe working load......................250kg
Head Section Raised from the horizontal........≥45°
Head Section lowered from the horizonta.........≥90°
Back Section Raised from the horizontal..........≥75°
Back Section Raised from the horizontal..........≥30°
Leg Section Lowered from the horizontal.........≥90°
Device safety sortI B Ingress Protection:IPX4
Power:(AC)220V,50Hz Battery capacity is 14 AH
Battery capacity ≥ 2.4AH
Structure:
1 The Electric operating table uses electro-hydraulic systems to control all the movements: height adjustment, trendelenburg and reversed trendelenburg, lateral tilt, back movements, forward and backward movement and brake. Head section, leg section and vertical rotation of tabletop are operated by manual operation.
2 The table comprises of five sections: head section, back section, Waist Section(When optional), sitting section and leg section. The forward and backward movement and 180 °rotation of tabletop can make C-arm perspective quick and easy.
3 Emergency power supply is Optional. Emergency power supply is made of lead-acid batteries, which can be automatically charged. Emergency power supply can start to work automatically when the power is off
| Numberal order | Name of accessories | Number | |
| 1 | Head section | 1 | |
| 2 | Anaesthetic Screen | 1 | |
| 3 | Body support | Large 1.smart 1 | |
| 4 | Shoulder support | 2 | |
| 5 | Arm rest | 2 | |
| 6 | Knee crutch | 2 | |
| 7 | Cushion | 1 | |
| 8 | Body Restraint Strap | 1 | Optional |
| 9 | foot plate | 2 | Optional |
