• Model NO.：HD-1
• Packing Size：2200*1010*580mm (Wooden Case)
• Height Adjust Range：650-895mm
• Product Type：Hospital Furniture
• Metal Type：Stainless Steel
• Transport Package：Wooden Box
• Origin：China
• HS Code：980000000
• Production Capacity：500PCS,Month

Main specification parameters:

Size: 2180mm(L)*970mm(W)*460/750mm(H)                                            packing size:2200*1010*580mm (wooden case)
1. the bed frame is made of epoxy coated steel, which is stable and reliable;
2. high quality ABS engineer plastic head/foot board and side rails;
3. four dia-125mm castors, with central locking system;
4. five functions , which can be operated by electric motor, the details is as follow:
 (1)back rest:0-80±2º          (2)knee rest:0-35±2º       (3) high-low:460~750mm
 (4) trendelenburg 20±2º      (5) reverse trendelenburg 20±2º
5. location for IV rod in both two sides
6. voltage: 110V~120V, 50HZ~60HZ or 220V~230V, 50HZ~60HZ
