• Model NO.：BD2020-A3
• 1 Carton Packing Weight：22.7kg
• Transport Package：6 Units in 1 Carton
• Specification：280mm*170mm*80mm
• Trademark：BODA
• Origin：Guangzhou

Basic Info.

Model NO. BD2020-A3 1 Carton Packing Weight 22.7kg Transport Package 6 Units in 1 Carton Specification 280mm*170mm*80mm Trademark BODA Origin Guangzhou

Product Description

Features:
1. Cold steel plate wholly molded surface, integrated frame treated with electrostatic spraying. Anti-aging and anti-rust,IPX4 protection against water and dust , motors Standard protection class: Ip54
2. PE head and foot board removable for CPR function
3. 4 pcs siderails with control system at both sides, Convenient operation for patients and nurses.
4. One set of Nursing pad with locking system, which can lock all the control, Examination function, Hypertensive and cardiac chair function and Alarm function(optional)
5. Manual and one key control electric CPR, easy and convenience to operate
6. Battery backup, used in case of power failure
7. Four dia125mm castors with central brake system
8. Angle Indicator: The angle indicator at each side rails, show the angles of back and leg section.
9. Foot section correct to horizontal position, convenient for patients when leg traction
10. Back section decompression function, make the patient more comfortable
11. Standards: IEC 60601-1, IEC 60601-2-52, ISO13485:2016
12.Certificate: CE, FDA


Dimensions:
1)L2220* W1040 *H460-700mm
2)Sleep size: L1945*W900mm2.
3)Angle of back section 0 ~ 70° (±5°)
4) Angle of leg section: 0 ~ 35°(±5°)
5) Angle of Trendelenburg and Reverse Trendelenburg: 0 ~ 13°(±2°)

Accessories:

1. Stainless steel IV pole with four hooks.
2. 4pcs Drainage bag holder, 2 holders in each side
3. Mattress(optional)

1,Are you a trading company or a supplier?
We are a manufacturer with Professional Medical Device Machines, Large Employees in China, it covers an area of more than 10000 square meters dust-free workshop, so that we can provide you High Quality Goods with Low Price.


2,How can I get a sample to check your quality ?
Free samples are available , but the freight charges can be paid by you.If we charge for samples , then the sample cost will be refund after order confirmation.


3,When can I get the quotation?
We usually quote within 24 hours after we get your inquiry . If you are very urgent to get the price , please call us or tell us in your email so that we will regard your inquiry priority .


4,How can I pay?
You can pay via T/T,L/C,D/P,ALIPAY.
