• Model NO.：FY011B
• Condition：New
• Load Capacity：6000 N
• Input Voltage：12 or 24V
• Stroke：50-1000mm
• Mini Install Dimension：S+175mm
• Limit Switches：Inner
• Warranty：2 Years
• Protection Class：IP43,IP65
• Type of Duty：S2-10min
• Usage：Furniture Equipment, Sofa, Chair
• Color：Black or Gray
• Transport Package：in Standrd Box or as Required
• Specification：CE, ROHS, SGS
• Trademark：JDR
• Origin：Jiangsu, China (Mainland)
• Production Capacity：1, 4000PCS,Month

Basic Info.

Model NO. FY011B Condition New Load Capacity 6000 N Input Voltage 12 or 24V Stroke 50-1000mm Mini Install Dimension S+175mm Limit Switches Inner Warranty 2 Years Protection Class IP43/IP65 Type of Duty S2-10min Usage Furniture Equipment, Sofa, Chair Color Black or Gray Transport Package in Standrd Box or as Required Specification CE, ROHS, SGS Trademark JDR Origin Jiangsu, China (Mainland) Production Capacity 1, 4000PCS/Month

Product Description

Input Voltage: 12V or 24 v DC

Load Capacity: 6000N

Max Speed: 6~36mm/s

Stroke: 0~1000mm(option)

Type of duty: S2-10min

Limit switches: Inner

Operation Temperature: -26--65 centigrade

Protection Class: IP43

Certification: CE/EMC+LVD, RoHS

Type: Furniture part

Material: Metal and plastic

Use: Chair

Place of origin: Jiangsu, China(mainland)

Function: Driving

Shape: Linear

Power: DC


High quality of electric linear actuator to worldwide customers. We are professional mamnufacturer in linear actuator.

Item: Electric Linear Actuator, Electric Linear Motor
Series: FY series
Item Number: FY011, FY012, FY013 FY04, FY015, FY016, FY017
Delivery time: 3~7 days for samples

High quality of electric linear actuator to worldwide customers. We are professional amnufacturer in Electric Linear Actuator and Electric Linear Motor.


Electric linear actuator is widely used in Adjustable beds, Medical beds, Wheel chairs, Patient hoists, Table height adjustments, Industry mechanical instruments, furniture, home beds, office tables, massage equipment, sporting equipments and so on and so on.

Specification of Our Electric linear actuator:
Max. Thrust: 4000N, 6000N, 8000N
Voltage: 24VDC or 12VDC, Motor Drive
Standard stroke: 100 / 150 / 200 / 250 / 300 / 350 / 400 mm, special stroke are available according to customer' requirement.
Duty cycle: 10%
Ambient temperature -26° C to +65° C
Standard protection class: IP 43
Built-in integral limit switch, not adjustable after leaving factory
Low noise design, dB<48(A); The inspection method is in accordance with DS/EN ISO3746 while linear actuator is unloaded.

Overload protection

CE Certificated

Availability in Black, White and Gray housing

Quality Guarantee
We provide 1 year warranty for JDR Linear Actuators.
We provide spare parts free or replace a new one on condition that there is any breakdown with convincing evidence.

Maintenance service
No matter what brands of your linear actuators, no matter where your linear actuators are from, full way service and technical Support could be supplied by JDR.

JDR QC Team
JDR QC team consists of more than 10 professional people to ensure 100% products high quality.

Contact Us
We highly appreciate your any enquiry by email, by fax or by Instant message.
We will reply your email or fax within 18 hours.
Please feel free to call us at any time if there is any question.

Transportation
All available shipping ways could be applied, by courier, by air or by sea.
Appointed shipping company or our own forwarders all could be used in shipment.
Full-way tracking the cargos for you before the goods arrive.

We have a wide range of Linear Actuator and Linear Motor for worldwide customer.

Name:	Linear  Actuator
Model:	FY011
Usage:	Electric  Bed,   Electric  Sofa,   Massage  Chair,   Dental  Chair,   other  Industrial  use
Input  Voltage:	12v  or  24v  DC
Load  Capacity:	750N,   1500N,   4000N,   6000N
Free  Load  Speed:	30mm/s,   18mm/s,   8mm/s,   4mm/s
Standard  Stroke:	50  mm  ---  1000mm  (Optional)
Installation  Dimension:	S  +  175mm
Type  of  Duty:	S2  --  10  min  (2  minutes  work,   18  minutes  rest)
Limit  Switch:	Builtin  /  Inner  (can  not  be  adjust  after  left  factory)
Work  Temp.:	-26  to  65  centigrade
Protection  Grade:	IP43,   IP54,   IP65
Certificate:	CE  /  EMC  +  LVD,   RoHS
Control  Box  Used:	Control  1  Linear  Actuator:   FYK011-1,   FYK012-1,   FYK015-1,   FYK016-1,   FYK017A
	Control  2  Linear  Actuators:   FYK011-2,   FYK012-2,   FYK015-2,   FYK016-2
	Control  3  Linear  Actuators:   FYK011-3,   FYK012-3,   FYK016-3
	Control  4  Linear  Actuators:   FYK012-4,   FYK016-4
	Control  5  Linear  Actuators:   FYK012-5,   FYK016-5
	Control  6  Linear  Actuators:   FYK016-6
Handset  Used:	All  FYH  Series  Handset,   Pls  contact  us  for  detail  pictures.
