• Model NO.：operation table
• Width：500mm
• Height：750-1000mm
• Transport Package：Standard Export Packing Box
• Specification：CE
• Trademark：Mermaid
• Origin：China
• Production Capacity：5000PCS,Year

Basic Info.

Model NO. operation table Width 500mm Height 750-1000mm Transport Package Standard Export Packing Box Specification CE Trademark Mermaid Origin China Production Capacity 5000PCS/Year

Product Description

Medical Equipment Hospital Operating Table Electric Surgical Table ECOH005-A

Electric Operating Table ECOH005-A Electric Operating Table ECOH005-A (99A)is designed for all kinds of operations in hospitals. Besides all functions of the Chinese-built operating tables.

DESCRIPTION

Electric Operating Table ECOH005-A

Electric Operating Table ECOH005-A (99A)is designed for all kinds of operations in hospitals. Besides all functions of the Chinese-built operating tables. It has its own advantages:
1. Leg section can be rotated, opened, disassembled and adjusted easily. It is most suitable for the urological operation.
2. The table top, made of highstrength plastic plate, can move backwards and forwards, X-ray examination can be carried out on it.
3. With 24V direct supply, the table is safe and reliable. The table's elevation, lowering, reversed trendelenburg; trendelenburg , lateral tilt are all automatically controlly by the Button.
4. This table can be disposed different kinds of table tops for different use.
5.The ascending and descending movements, lateral tilt movements,reversed trendelenburg, trendelenburg movements adn backward and forward movements of the table top are all electrically operated.
Electric Operating Table is one of the most advanced operating table with excellent functions in China. Availabe for the Model C arm.
The back section and the leg section of Model ECOH005-A
is equiped with the barometric Pressure spring. Senior PY foam material is optional for mattress.

Specifications

Dimension of table top:
Overall Length/Width: 2100mm/500mm
Table top of from floor
Height: 750-1000mm
Reversed Trendelenburg/ Trendelenburg: ≥20°/≥15°
Lateral Tilt: ≥15°
Backward and Forward Movements: ≥400mm
Head Section Raised/ lowered from the horizontal: ≥45°/≥90°
Back Section Raised from the horizontal: ≥45°
Kidney Bridge Elevated: ≥80mm
Leg Section Lowered from the horizontal: ≥90°
Leg section opened: ≥90°
Safe working load: 135kg
Foot and leg board board into a horizontal or vertical.
(DC)24V  Internal electric source:(DC)24V
Battery capacity ≥ 2.4AH
