• Model NO.：Bxd100b
• Usage：Patient Chair, Transfusion Chair
• Color：Green
• Customized：Customized
• Condition：New
• Size：1900*850*560mm
• Certifications：CE and ISO13485
• Sample：Available
• General Use：Commercial Furniture
• Factory Location：2.5 Hours Drive From Shanghai
• OEM：Available
• User′s Manual：Available
• Transport Package：Wooden Case
• Specification：ISO, CE
• Trademark：WANROOEMED
• Origin：China
• HS Code：94014090
• Production Capacity：500PCS, Month

Basic Info.

Model NO. Bxd100b Usage Patient Chair, Transfusion Chair Color Green Customized Customized Condition New Size 1900*850*560mm Certifications CE and ISO13485 Sample Available General Use Commercial Furniture Factory Location 2.5 Hours Drive From Shanghai OEM Available User′s Manual Available Transport Package Wooden Case Specification ISO, CE Trademark WANROOEMED Origin China HS Code 94014090 Production Capacity 500PCS/ Month

Product Description

Bxd100b One Button Flat Electric Double Function Electric Phlebotomy Dialysis Blood Donation Donor Collection Chair with Saltwater Rack
Description:
1. Designed according to the principle of human body engineering, luxurious, comfortable and durable. You won't get tired if you sit too long.
2. The blood collection chair consists of four main parts: backrest, seat, leg plate and foot pedal.
3. It carries out the linkage movement of back, legs and back legs through the electric remote control.
4. Wide and comfortable handrails support blood collection
5. Extendable foot pedal boards provide patient comfort and comfort.
6. Q235 steel pipe is durable, cushion is made of imported PVC high-quality artificial leather, polyurethane one-time molding;
7. Four-inch casters, each wheel can be individually locked and the seat can be fixed in the desired position.
8. Standard saltwater rack
9. The chair can be easily used for blood collection and dialysis procedures.
10. Optional: Dining table

Easy Operate
1. Electric CPR function, one button flat, optional manual CPR.
2. The back and legs can be adjusted up and down to achieve a Trendelenburg position of plus or minus 12 degrees
3.The dialysis position with legs greater than 12 degrees can be presented.

Adjustable position:
seat position
semi-fowler position
horizontal position
CPR Trendelenburg position

Main Parameter	Electric Control
Model	BXD100B
Chair open size	1900*850*560mm
Chair body size	920*850*560mm
Package size	1620*820*600mm/72kg
Seat width	600mm
Arm rest adjustment height	none
Chair Adjustment Range
Height Adjustable	none
Back adjustment Angle range:	-10° ~ 75°±5°
Leg plate Adjustment Angle range:	-80° ~ 12°±5°
Trendelenburg position:	-12°
IV pole(from clamp to top)	860~1500mm
IV pole(from floor to top)	1260~1900mm
Paper holder and oxygen holder diameter:	none
Material
Frame Material	Steel
Matress Material	PVC
Wheel	4 Silent Wheels With Brakes
Max loading	200kg
N.W/G.W.	62kg/75kgs
Power Supply	AC220V  50Hz/60Hz
