• Model NO.：FY012
• Protection Class：IP54
• Limit Switch：Inner
• Mini Install Dimension：S+175mm
• Warranty：2 Years
• Color：Gray or Black
• Speed：6mm,S
• Application：Medical Bed
• Transport Package：in Standrd Box or as Required
• Specification：6000N
• Trademark：JDR
• Origin：Jiangsu, China (Mainland)
• Production Capacity：1, 4000PCS,Month

Basic Info.

Model NO. FY012 Protection Class IP54 Limit Switch Inner Mini Install Dimension S+175mm Warranty 2 Years Color Gray or Black Speed 6mm/S Application Medical Bed Transport Package in Standrd Box or as Required Specification 6000N Trademark JDR Origin Jiangsu, China (Mainland) Production Capacity 1, 4000PCS/Month

Product Description

Item No. FY012

Input Voltage: 24 v DC

Load Capacity: 2000N/4000/6000N

Max Speed: 4MM/S(4000N), 9mm/s(2000N)

Stroke: 0~1000mm(option)

Type of duty: S2-10min

Limit switches: Inner

Operation Temperature: -26--65 centigrade

Protection Class: IP54

Certification: CE/EMC+LVD, RoHS

Type: Furniture part

Material: Metal and plastic

Use: Traction bed


Place of origin: Jiangsu, China(mainland)

Function: Driving

Shape: Linear

Power: DC

More inforamtion

1) 24VDC permanent magnet motor

2) Thrust up to 6000N in push, and up to 4000 N in pull

3) Elegant and compact design with small instanllation dimensions

4) Built-in limit switches ( not adjustable after leaving factory )

5) Aluminium or zinc outer tube / inner tube

6) Electric chromate steel piston rod eye with slot

7) High-strength plastic housing protects motor and gears

8) Standard protection class: IP 54

9) Scratch and wear-resistant power painting

10) Noise level < 50 dB

11) Warranty: Two years

12) Duty cycle: 10%, or 2 munutes continous working followed by 18 minutes not in use

High quality of electric linear actuator to worldwide customers. We are professional mamnufacturer in linear actuator.

Item: Electric Linear Actuator, Electric Linear Motor
Series: FY series
Item Number: FY011, FY012, FY013 FY04, FY015, FY016, FY017
Delivery time: 3~7 days for samples

High quality of electric linear actuator to worldwide customers. We are professional amnufacturer in Electric Linear Actuator and Electric Linear Motor.


Electric linear actuator is widely used in Adjustable beds, Medical beds, Wheel chairs, Patient hoists, Table height adjustments, Industry mechanical instruments, furniture, home beds, office tables, massage equipment, sporting equipments and so on and so on.

Specification of Our Electric linear actuator:
Max. Thrust: 4000N, 6000N, 8000N
Voltage: 24VDC or 12VDC, Motor Drive
Standard stroke: 100 / 150 / 200 / 250 / 300 / 350 / 400 mm, special stroke are available according to customer' requirement.
Duty cycle: 10%
Ambient temperature -26° C to +65° C
Standard protection class: IP 43
Built-in integral limit switch, not adjustable after leaving factory
Low noise design, dB<48(A); The inspection method is in accordance with DS/EN ISO3746 while linear actuator is unloaded.

Overload protection

CE Certificated

Availability in Black, White and Gray housing

Quality Guarantee
We provide 1 year warranty for JDR Linear Actuators.
We provide spare parts free or replace a new one on condition that there is any breakdown with convincing evidence.

Maintenance service
No matter what brands of your linear actuators, no matter where your linear actuators are from, full way service and technical Support could be supplied by JDR.

JDR QC Team
JDR QC team consists of more than 10 professional people to ensure 100% products high quality.

Contact Us
We highly appreciate your any enquiry by email, by fax or by Instant message.
We will reply your email or fax within 18 hours.
Please feel free to call us at any time if there is any question.

Item No.	FY012
Input voltage	24VDC/12VDC
Load capacity	6000N
Max speed	3mm/s (6000N)
Stroke	50-1000mm
Type of duty	S2-10min
Limit switches	inner
Operation temperature	-26-65degree
Color	Black or gray
Protection class	IP54
