• Model NO.：ECOH007
• Table Height：750mm~1000mm
• Length and Width：2100mmx480mm
• Reversed Trendelenburg/Trendelenburg：20o
• Lateral Tilt (Left/Right)：15o
• Head Rest(up/Down)：45o,90o
• Kidney Bridge Elevated：100mm
• Leg Section Lowered From The Horizontal：90o
• Safe Working Load：135kg
• Transport Package：Standard Export Packing Box
• Specification：CE
• Trademark：MEDECO
• Origin：China
• Production Capacity：5000PCS,Year

Basic Info.

Model NO. ECOH007 Table Height 750mm~1000mm Length and Width 2100mmx480mm Reversed Trendelenburg/Trendelenburg 20o Lateral Tilt (Left/Right) 15o Head Rest(up/Down) 45o/90o Kidney Bridge Elevated 100mm Leg Section Lowered From The Horizontal 90o Safe Working Load 135kg Transport Package Standard Export Packing Box Specification CE Trademark MEDECO Origin China Production Capacity 5000PCS/Year

Product Description

Electric  Operating  Table ECOH007

This bed is suitable for surgical procedures of the head, neck, thorax and abdomen, perineum and extremities as well as for gynaeclolgical, oto-rhino-laryngological and orthopaedics operation., The table top, made of double-decker plastic plate, X-ray examination may be carried out on it while the operation. It's raising, lowing, lateral tilt,reversed trendelenburg and trendelenburg movement,back section bending are all controlled by electrically. It's adjustment easy, performance is reliable

Main Usage & Structure:

Electric operating table is suitable for surgical procedures of the head, neck, thorax, abdomen perineum and extremities as well as for gynaecological, obstetrical, urological, otorhino laryngological and orthopaedics operations. It's raising, lowering, lateral tilt, reversed trendelenburg and trendelenburg , the up-down folding of the back section are all conducted electrically and controlled by buttons.


Dimension of table top:
Overall Length.......................................…2100mm
Width.............................................….........480mm
Dimension of section:
Head Section.......................................…..280×325mm
Back Section.........................................….500×480mm
Seat section.......................................…... 530×480mm
Leg Section.......................................….. ..510×236mm
Foot Section.......................................… ..180×273mm
Kidney Bridge.......................................…100×480mm
Table top of from floor:
Max Height................................................1000mm
Min Height................................................750mm
Range of movements:
Reversed Tendelenburg..........................................   ...≥20⁰
Trendelenburg...............................................................≥15⁰
Lateral tilt..........................................…..........................≥15⁰

Adjustment of sections:
Head Section Raised from the horizontal....................... ≥45⁰
Head Section lowered from the horizontal.......................≥90⁰
Leg Section Lowered from the horizontal...............…......≥90⁰
Leg Section opened....................................................….≥90⁰
Back Section Raised from the horizontal..........................≥45⁰
Back Section lowered from the horizontal.........................≥15⁰
Kidney Bridge Elevated....................................................≥100mm
Safe Working Load..........................................................135kg
 Lifting speed................................................................4~16mm/s
Foot and leg board board into a horizontal or vertical.

IPX4   Ingress Protection:IPX4
Power: AC220V,50Hz
Internal electric source:(DC)24V
Battery capacity ≥ 2.4AH Device safety sort  I     B


Numberal order	Name of accessories	Number
1	Head section	1
2	Stand for anaesthetic bottle	1
3	Body support	Large 1.smart 1
4	Shoulder support	2
5	Arm rest	1
6	Knee crutch	2
7	Cushion	1
8	Foot Section	2
9	Body Restraint Strap	1	Optional
10	Handle	1

Structure:

Electric Operating Table is made up of the table top, the main part, the electric controlling part and the accessories, etc. It's raising, lowering, lateral tilt, trendelenburg and reversed trendelenburg movements ,back section bending are all drived by the motors.

The table top is made up of head section, back section, seat section, leg section and kidney bridge. The head section can be disassembled. The head section can be raised or lowered from the horizontal. The leg section can be lowered from the horizontal and opened. The back section can be raised or lowered from the horizontal. Table top is made of engineering plasties, thus X-ray examination of can be carried out on it.

The main part includes rotary frame, lateral tilt arrangements, trendelenburg and reversed trendelenburg arrangements, ascending and descending arrangements and the base.
