Emergency Hydraulic Patient Transfering Stretcher/Trolley for ICU
Better Medical Technology Co., Ltd.- Color：White
- Folded：Unfolded
- Certification：ISO, FDA, CE
- Material：Steel Power Coated + PP
- Number of Belts：0
- Type：Ambulance Stretcher
Base Info
- Model NO.：BT202
- MOQ：5PCS
- OEM：Available
- Warranty：1 Year
- Application：Hospital,Ambulance
- Transport Package：Carton
- Specification：1900*730*850-1085mm
- Trademark：better medical
- Origin：China
- HS Code：8716800000
- Production Capacity：2000,Month
Description
Bed board size:1900x600mm
Hi-lo adjustable:580-815mm(from ground to bed board)
Backrest adjustable:0~60°
Trendelenburg&reverse:0~13°
Castors:150mm(6")
Fifth wheels:125mm(5")
N.W:85kgs
Max loading:175kgs
Steel powder coated frame
PP side rails
ABS bed board
rubber castors
stainless steel I.V pole
4pcs 5" luxurious castors with central-controlled brake system,
2 pcs of PP side rails,
1 set of crank system,
1 set of backrest adjusting hydraulic pressure pole,
1pc oxygen tank holder
2pcs I.V drip stand holder
1 set of steering deviece,
1 pcs of mattress.
1pc I.V drip stand
5pcs pedal
Cleaning and maintenance
General cleaning for stretcher and side rail
Clean it with soft cloth which dip with diluted neutral detergent ,then clean off the diluted neutral detergent by cloth with clean water , finally, wipe it with dry cloth.
Do not use volatile items (diluent, volatile agents, gasoline)
Not available for high temperature ,
Please select low temperature sterilization method
Preventive safety inspection and maintenance
Preventive safety inspection and maintenance only allowed for Professionals
Check stuck situation , loose fasteners and any presence of safety risks.
Add lube to the moving parts to assure smooth working
Inspection and maintenance intervals for 1 year
Storage
Avoid store it in extreme cold,heat,dust or humidity environment
Optimum temperature in - 10 ºC to 40 ºC, relative humidity less than 80% RH, atmospheric pressure range: 760 hpa ~ 1060 hpa.
No corrosive gas, well-ventilated room.
Adjust the height of this stretcher to the lowest .do not put staff on the stretcher, especially
heavy staff
Please keep this user manual well
Required horizontal transportation, forbidden to flip case during transport
Quality assurance and after-sales service
Please operate the stretcher following the user manual and the instruction label
Call us for technical support if quality problem
We supply a warranty for 1 year
NO Free warranty service for situation below:
(1) Failure and damage caused by unauthorized dismantling and repair
&improper operation by the user &
(2) Failure and damage caused by misassembling ,delivery & moving
(3) Failure and damage caused by earthquake, fire, smoke, abnormal voltage, lightning, flood and other natural disasters
